Creation of geometries by Coordinate system methods using AutoCad

P1.)

1. First select the line tool
2. Type the given point.
3. Then dx =0 and dy =7
4. dx=1 and dy =0
5. The dx =5 dy =0
6. dx=0 dy=-1
7. dx= -5 dy =0
8. dx=5dy=0
9. dx=1 dy =0
10. dx=-6 dy=0
11. Then join the line.

P2.)

1. Using line tool plot 2,1
2. press first @ for every point
3. dx=0 dy = -7
4. dx=2 dy = 0
5. dx = 3,dy = 0
6. dx = 0 dy = 7
7. dx =-3,dy=0
8. dx =0 dy=4
9. dx=-1,0
10. dex=0 dy= -4
11. dx= -3,0

P3.)

1. Line tool points 2,1
2. press first @ for every point
3. dx=0,dy=7
4. dx=1,dy=0
5. dx=2.dy-3
6. dx=2,dy=3
7. dx=1,dy=0
8. dx=0 dy=-7
9. dx=-1,dy=0
10. dx=0 ,dy=4
11. dx=-2,dy=-2
12. dx=0,dy=-4
13. dx=-1,dy=0

P3.)

1. Line tool point 2,1
2. press first @ for every point
3. dx=0,dy=8
4. dx=7,dy=0
5. dx=0,dy=-8
6. dx=-4,dy=0
7. dx=0,dy=1
8. dx=3,dy=0
9. dx=0,dy=6
10. dx=-6,dy=0
11. dx0,dy=-7
12. dx=-1,dy=0

P4.)

1. Line tool point 2,1
2. press first @ for every point
3. dx=0,dy=6
4. dx=8,dy=0
5. dx=0,dy=-6
6. dx=-8,dy=0
7. dx=0,dy-1
8. dx=2,dy=0
9. dx=0,dy-=3
10. dx=-2,dy=0
11. dx=0,dy=-2
12. point 3,1
13. dx=2,dy=0
14. dx=0,dy=3
15. dx=-2,dy=0
16. dx=0,dy=-3

P5.)

1. Line tool 2,1
2. dx=0,dy=6
3. dx=8,dy=0
4. dx=6,dy=0
5. dx=-8,dy=0
6. line tool 3,2
7. dx=2,dy=0
8. dx=0,dy=3
9. dx=-2,dy=0
10. dx=0,dy=-3
11. Line point 3,4
12. dx=2,dy-0
13. dx=0,dy=3
14. dx=-2,dy=0
15. dx=-2,dy= 0

P6.)

1. line tool point 0,0
2. dx=0,dy=2
3. dx=4,dy=0
4. dx=0,dy=4
5. dx=-3,dy=0
6. dx=-0,dy=2
7. dx=8,dy=0
8. dx=0,dy=-2
9. dx=-3,dy=0
10. dx=0,dy-4
11. dx=4,dy=0
12. dx=0,dy=-2
13. join the line

P7.)

1. line tool point (1,1)
2. dx=5,dy=0
3. dx=0,dy=2
4. dx=-3,dy=0
5. dx=0,dy=-1
6. dx=-1,dy=0
7. dx=0,dy=2
8. dx=3,dy=0
9. dx=0,dy=-2
10. dx=-4,dy=2
11. dx=0,dy=-7

P8.)

1. Line tool point 1,1
2. dx=0,dy=7
3. dx=0,dy=5
4. dx=0,dy=-4
5. dx=-3,dy=0
6. dx=0,dy=-3
7. dx=2,dy=0
8. plot the balance points

p9.)

1. line tool point 0,0
2. dx=0dy=1
3. dx=2,dy=0
4. dx=0,dy=5
5. dx=-2,dy=0
6. then point unit 5.831<30.64 degree
7. the point 0.0
8. sx=10,dy=0
9. dx=0,dy=1
10. dx=-2,dy=0
11. dx=0,dy4
12. dx=2,dy=0
13. dx=0.dy=1
14. from the pointr unit 5.831<120.36 degree
15. plot the circle 5,4

P10.)

1. Line tool point 1,1
2. dx=0,dy=4
3. dx=7,dy=0
4. unit 5 <135 degree
5. unit 5<135 degree

P11.)

1. Line tool point 1,1
2. dx=2,dy=0
3. dx=2,dy=0
4. dx=2,dy=0
5. join the above lines
