REPORT ON BASE BRACKET DESIGN Creating the Base Bracket Plastic component through the given Class-A surface. To begin, the tooling axis for the given Class-A Surface should be created. TOOLING AXIS:                       The direction in which the mold or core…

 REPORT ON SWITCH BEZEL DESIGN Creating the Switch bezel plastic component through the given Class-A surface. To begin, the tooling axis for the given Class-A Surface should be created. TOOLING AXIS:                       The direction in which the mold or core…

 REPORT ON COIN HOLDER Creating the COIN HOLDER plastic component through the given Class-A surface. To begin, the tooling axis for the given Class-A Surface should be created. TOOLING AXIS:                       The direction in which the mold or core and…

PLASTIC BUMPER DESING OF A CAR: Creating the BUMPER plastic component through the given Class-A surface. To begin, the tooling axis for the given Class-A Surface should be created. TOOLING AXIS:                       The direction in which the mold or core and…

AIM: Creating the core and cavity blocks for the SWITCH BEZEL Design. TOOLING AXIS:                       The direction in which the mold or core and cavity opens is the tooling axis. In moulding , the direction in which the mould (core and cavity) is allowed…

AIM : Create the rib and Screw boss for the Drill Handle considering the design rules.  Tooling axis & Draft Analysis: The direction in which the mold or core and cavity opens is the tooling axis.  To create the tooling axis, I extracted a surface from class A and created a point in the middle of the surface by using the…

REPORT OF DOG HOUSE FOR THE DOOR TRIM DESIGN: Aim : To create the Dog House For Door Trim Plastic component through the given Class-A surface. To create the tooling axis for the given Class-A Surface meeting the requirements of the draft angle and at the end perform the Draft analysis on the final model.  Introduction:…

DOOR TRIM LOWER Aim: To Create the Door trim lower with Engineering Features component through the given Class-A surface. Objectives: Creation of Tooling axis with appropriate draft angle. Creation of other surfaces (eg, B and C surfaces) for creating a solid component. Perform Draft analysis on Class A surface and Solid…

  DESIGNING A PILLAR USING MASTER SECTION:   AIM: 1) To improvise the Class B surface by resolving patches. 2) To create A pillar solid model with the help of improvised Class B surface. 3) To create B side features for the A Pillar using the master section given to us as an input. 4) To create main and…

  THE 3-2-1 PRINCIPLE: Locating a part to be machined involves mainly three steps: supporting, positioning and clamping. Two main intentions when placing a job on a jig/fixture are: Precisely positioning the part at the desired coordinates. Curbing all six degrees of movement so that the part cannot budge. An extensively…

REPORT FOR DOOR PANEL DESIGN: Aim : To create the Door Panel Plastic component through the given Class-A surface.  Creation of CAD model considering following inputs as like in OEM and tier1 companies             a) Class A surface             b) Nominal thickness : Refer master sections             c) Attachment strategy…
