*********** Comments by Grader ************ 1. The code was not inserted using the Insert code option. 2. The report is not provided in a detailed manner. Does not contain the errors faced and steps taken to overcome them. 3. The drag coefficient vs drag force graph is not a line plot because all cd values were not taken…

Objective:           To create a 3Dmodel for IC Engine Valve Train and assemble and performed a motion analysis and also to study contact force between parts. Components used in IC Engine valve train: Cam:           A camshaft is a device to convert rotational motion into…

AIM: To determine the PV diagram and Thermal Efficiency of the engine.CODING:close allclear allclc%input parametersgama = 1.4%engine paramatersbore = 0.1stroke = 0.1con_rod = 0.15cr = 12a = stroke/2r = con_rod/a%calculation of swept volume and clearance volume v_swept = (pi/4)*bore^2*stroke;v_clearance = v_swept/(cr-1);%state…

AIM: To determine the external pipe flow simulation by using wizard option, and increase the reynolds number by a factor of 20%, 40%, and 100% and then run the transient flow simulation.   DIMENSIONS OF THE MODEL: D = 2 mm. length = 5mm.   PARAMETERS TO BE CONSIDERED: Fluid = air. rho = 1.225 kg/m3 mu = 1.81…

AIM : In this project, we are creating a 3D model of a Flow Bench and runing the flow analysis & perform the following operations.  Grid dependence test                    For three grids run your simulation at a particular valve lift and explain your results.…

Objective  To create a 3D model of Centrifugal Pump, and run a baseline flow simulation of Inlet flow as atmosphere Pressure and then preform Outlet flow as a parametric study with different velocities condition and showing the Performance diagram. Obtain the relationship between Pressure ratio and mass flow…

AIM: To determine the code to fit a linear and cubic polynomial for the Cp data. CODE: clear all close all clc %preparing the data cp_data = load('data'); temperature = cp_data(:,1); cp = cp_data(:,2); %curve fit for 1 degree polynomial %cp = a*t + b co_effs1 = polyfit(temperature,cp,1); predicted_cp1 = polyval(co_effs1,temperature);…

AIM: TO compare the performance of three types of beams under a bending load and compare the results of stress, displacement and strain for all the three cases and suggest the best out of the three. Basic Parameter:  (All Dimensions are in mm) Load                  - 1500…

AIM: To calculate the global maxima of a Stalagmite Function by using Genetic Algorithm EXPLANATION OF GENETIC ALGORITHM:     A genetic algorithm (GA) is a method for solving both constrained and unconstrained optimization problems based on a natural selection process that mimics biological…

*********** Comments by Grader ************1. The  errors faced and steps taken to overcome them were not mentioned.2. The axis of the animation plot was not correct so the movement of the second could not be properly visualised. Marks have been deducted for the above reasons. SUGGESTION : The other thing that you can do is to attach the code and images in…

AIM: Creating a 3D model using solidworks and  performing a static analysis on two models of plate with holes. Material Properties Elastic Modulus 2.1e+011 N/m^2 Poisson's Ratio 0.28 N/A Shear Modulus 7.9e+010 N/m^2 Mass Density 7700 kg/m^3 Tensile Strength 723825600 N/m^2 Compressive Strength N/m^2 Yield Strength…

  AIM: To model the flow over a NACA0017 Airfoil For the angle of attacks 0,2,4,6,8,10 compare the lift and drag forces.   PROCEDURE:  X,Y,Z Curve points are inserted from the given sample of NACA0017 Airfoil. Converts the curve as entities and join the entities at end,  Movie the entities at which…

AIM: To determine the internal pipe flow simulation by performing parametric studies, Different ReynoldNumer (re) are given 100,1000,1000, and with a different line probes from totel length of the pipe.     DIMENSIONS OF THE MODEL: Length - 1000mm Inner dia - 5mm Outer dia - 6mm   PARAMETERS…

Objective:           To create 3D model for Planetary Gear with a sun gear, a ring gear, four planet gear and also create a carrier to hold the four planet gear and performing a motion analysis by rotating the gears at the speed of 200rpm. And also to study angular velocity of gears. About Planetary…

AIM Perform a buckling analysis on a cyclonic separator stand. Create a metallic stiffener on the legs of the stand and run the analysis to find out the change in buckling factor of safety. The next step is to run a design study and find the optimum position for the stiffener. Buckling          …

  Objective  Create the 3D model to find out the critical frequencies of a rotating shaft in Solidworks. and 5 mode shapes and list the resonant frequencies.  Model Dimension Material Properties Elastic Modulus 2.1e+011 N/m^2 Poisson's Ratio 0.28 N/A Shear Modulus 7.9e+010 N/m^2 Mass Density 7700 kg/m^3…

Objective:            To create a 3D model for Piston Assembly and parts are performed a motion analysis and also to study liner displacement of the Piston head assembly. Piston Assembly Parts. Piston:           A piston is a component of reciprocating engines, reciprocating…

Objective  To determine the fatigue analysis on S hooks damage and life  Material Properties  Elastic Modulus 7.8e+010 N/m^2  Poisson's Ratio 0.42 N/A  Shear Modulus 2.6e+010 N/m^2  Mass Density 19000 kg/m^3  Tensile Strength 103000000 N/m^2  Compressive Strength N/m^2  Yield…

Objective:      To Create 3D model for driver and driven wheel of Internal Geneva Mechanism and perform motion analysis by rotating the driver wheel at 10rpm and 20rpm and compare the contact force as a function of time between driven and driver wheel at 10rpm and 20rpm with and without precise…

AIM: To solve the second order ODE and to simulate the Motion of Simple Pendulum using Matlab. Here, We are using equation for motion of a simple pendulum with damping In the above equation, g = gravity in m/s2, L = length of the pendulum in m, m = mass of the ball in kg, b=damping coefficient. CODING: Main Program: clear…

OBJECTICE:        To parse the themodynamic data file and to calculate the themodynamic properties of gas species present in the file. AIM:            14 co-efficients and calculates the enthalpy, entropy and specific heats for all the species and Calculating the molecular…
