Week 8 - Challenge 6 - Core & Cavity Design

SWITCH BEZAL CORE AND CAVITY

TOOLING AXIS CONSTUCTION

Tooling axis for this componants is already made by bisecting methode in some week ago`s challenge.

in this bisecting method first of all take flat surface extude it and make a ponit on it and dreaw dummy line from that point. after that taking intersection of two line which are parellel to the dummy line and extent the line . after that draw aline by selecting bisecting option and the line is called as tooling axis or tooling line.
