Week 4- Meshing of Backdoor Challenge

AIM:

To mesh the given component with given quality criteria

PROCEDURE:

STEP1;

Import the given model and apply the criteria values

STEP2;

To apply the given model midsurface or offset in each component(three components)

STEP3;

Automesh the component one by one with element size

STEP4;

Remesh the components to fail elements

STEP5;

In fail elements to use the quality index to correct the each components

RESULT;

To finish the mesh in all components
