Week 2 Challenge

1. The WorkSpace and WorkSet are two levels where standards can be defined. A common way to use these are for the WorkSpace to define Site or Company standards and the WorkSet to define Project specific standards.

It is important to understand that the WorkSpace and WorkSets delivered with the current OpenRoads Designer Early Access Preview software were configured specifically for the sample data in this preview environment, not for a production environment. These will be changing before the commercial release with the WorkSpace and WorkSet configured more appropriately for a production environment.

Default location:

C:\ProgramData\Bentley\OpenRoads Designer CE\Configuration\

2.A feature definition can be selected from the Feature Definition Toggle Bar or on tools from the horizontal geometry tasks to define the feature.

An element can also be converted to a feature using the Set Feature Definition Tool. Documentation on the Feature Definition Toggle Bar can be found under the OpenRoads Help task menu. Default toggles can be controlled in CADD menu > Workspace > Preferences > View Options - Civil > Toggle Commands section.

Note: the Toggle Commands section may not be visible. If it isn't, exit the Preferences dialog, select any design tool from the Civil Tools task menu and and open the Preferences dialog again. After changing, use the Save Settings command to save any changes.

3. FILE ATTACHED BELOW

4.FILE ATTACHED BELOW
