V-Block Assembly : Week 4 Challenge

AIM:

• In this assignment, we will be given a V-block assembly.
• we have to recreate the same images in Catia using the sketching tools covered in this week’s tutorials.

GIVEN:

MODEL 1:

Used commands:

• constraints
• trim
• line
• circle
• Axis
• Circle
• plane etc...

After the creation of the individual body parts, use the assembly window to constraint the bodies

Used commands for Assembly:

• coincidence constraint
• face constraint
• offset constraint
