Project 1 : CFD Meshing for Tesla Cyber Truck

Aim: For Given model, check and solve all geometrical errors on half portion and Assign appropriate PIDs. Perform meshing with the given Target length and element Quality criteria.

steps:

• Open the model from the directory

Geometry cleanup:

Topo

• Hot points__ insert,project,parametrical,delete,release.
• Cons_paste,release, fill hole, project.
• Faces_new,cut,delete,set PID,Topo,Projectcut, Extend,
• Curves_create,delete,Undelete,
• points_create, delete,Relative,
• Auxiliaries_Fine,and More..,

Mesh

• Perimeters_length,Number,num+-,spacing
• Mesh Generation_CFD mesh,spot mesh and more..,

Used :Topo option

https://drive.google.com/file/d/14i9leahk88m6t2wLkcU1516RfgTVY2KN/view?usp=sharing
