Creating a Layout, Section and Elevation with dimensions using AutoCad

AIM: To Create the Plan and Sections

PROCEDURE:

OPEN AUTO CAD

SET REQUIRED UNITS IN DECIMAL MM

USE LINE COMMAND TO DRAW THE LINES

USE OFFSET COMMANDS TO TAKE ODFFSET OF 230MM FOR OUTER WALL AND 150MM FOR INNER WALL

USE TRIM COMMAND TO TRIM THE UNNESSESARY LINES

USE BLOCK COMMONDS TO CREATW COLUMNS

DEFINED DIFFRENT LAYERS FOR FLOOR PLAN, ELEVATION AND SECTION

COMMAND USED;

LINE COMMAND

TRIM COMMAND

OFFSET COMMAND

MTEXT COMMAND

COPY COOMAND

MOVE COOMAND

MIRROR COMMAND

CONTINOUS LINE TO TAKE LINES FROM PLAN TO ELEVATION

TRIM THE LINES AFTER WE GET REQUIRED DIAMENSTIONS

RESULT:
