FUEL CELL for EV vehicle A Proton Exchange Membrane Fuel cell stack having an average vale of 100v DC/DC convertor is used. A 50kW with 635Vdc fuel cell stack is selected. The properties of the fuel cell are listed below Working: Signal builder block is provided to the fuel system. The fuel flow rate increases in accordance…

AIM : Making and analsing A123 cell having battery pack capacity of 18 KWh DESCRIPTION: Cell : ANR26650M1-B  Model # ANR 26650 M1B Charging current Standard Charging: 2.5A, 1.0C rate  Maximum Charging: 10.0A, 4.0C rate Discharging current Maximum Continuous Discharging  :50A, 20C rate Maximum Impulse Discharging…

Simulating the generic battery model using the UDDS data and studying the Battery characteristics using plot of SOC, Voltage and current with the time. The figure shown is the Simulink block diagram to study the generic battery behaviour.   The generic battery has the following default characteristics: Nominal Voltage…

Fault in MATLAB BMS_Closeloop Model The Model represents a rough idea on how the BMS reacts and gives user an idea of any fault occuring in the Battery Pack, if any. The model here allows the user to know the error by glowing the RED Light on the dashboard. The various defects that can occur are  Fault State over…
