Aim:- To create a 3D model of internal geneva mechanism using solid works. Theory:- An internal Geneva drive is a variant on the design. The axis of the drive wheel of the internal drive can have a bearing only on one side. The angle by which the drive wheel has to rotate to effect one step rotation of the driven…

Aim:-To create a row and column vector in matlab Code:-   clear all close all clc %To create a row vector in matlab a = [1, 2, 3] %To create a column vector in matlab b = [7; 8; 9]

The program to calculate the drag force and to plot the graph between velocity and drag force. The program has been explained in the form of comments during coding % A program calculate drag force against a cyclist. clear all close all clc % Inputs that are required to calculate drag force for a cyclist. % Drag coefficient…

Aim:- To write a program in Matlab that will simulate the pendulum motion. Theory :- By using the below equation we have to calculate the position of the bob during the pendulum motion It's an second degree equation so first of all we have to convert it into a simple form Let `theta = theta 1` `d/dt theta1…

Aim :-  Analysis of Planetary gear system. Objective :-  Use the following dimensions to create a assembly in solid works. Use the following inputs for designing the Planetary Gear Ring Gear Module = 2.5 (You must use the metric system in design modeler) Number of teeth = 46 Sun Gear Number of teeth = 14…

Aim :- MBD Simulation on IC Engine Valve Train using Solidworks. Objective :-  To create a 3D model of IC engine valve train using solidworks of cam lift 3.5mm and 6mm respectively. Plot the graph of linear displacement of the valve and contact force between the components in each of the two cases. Software…

Aim :- MBD Simulation on a Piston Assembly. Software Used :- Solidworks 2019 Objective :- Model all the parts and then assemble them in SolidWorks. The motion analysis is going to be carried out in three different condition Conditions : 0mm Wrist Pin Offset, Crank speed- 2000rpm 10mm positive Wrist Pin Offset,…

Aim :- Expanding Pulley mechanism Software Used :- Solidworks 2019 Objective :-  To create a cad model, animation and motion analysis of the expanding pulley mechanism using solidworks.   Parts to be modeled :- Base Central gear Pulley Segment Pinion Theory :- In an expansion-pulley composed of a series of rim-segments…

Aim :-  Parsing NASA thermodynamic data Software Used :- Matlab 2016a Program :-  The following is the programm  clear all close all clc f1 = fopen('THERMO.dat','r') file_name = fgetl(f1); tline_1 = fgetl(f1); A = strsplit(tline_1,' '); global_low_temp=str2num(A{2}); global_mid_temp=str2num(A{3}); global_high_temp=str2num(A{4});…
