Wiring harness design in CATIA V5 - 3D modeling Week 5 & 6 Challenge

AIM:

To Route two electrical harnesses as per the given layout and interconnect them as a single harness assembly and then check for bundle continuity, bundle warnings, and then give annotations to the final harness assembly.

OBJECTIVE:

1. The objective of this project is to first route the two Harness A and Harness B as per the given harness layout.
2. Bundle continuity has to be checked for the two created harness.
3. After the two Harnesses are created, the next objective is to have them interconnected     electrically.
4. Check for bundle warnings in Harness A and Harness B.
5. Add annotations to all the connectors in Harness A and Harness B.
6. The final objective of this project is to convert the final harness file into IGS file format.

PROCEDURE:

The following steps are to be done to complete this project.
