Week 8 - Challenge 3 - Coin Holder Design

AIM

• TO MAKE THE MODEL FOR THE CLASS A SURFACE

INTRODUCTION

• TO CREATE THE MODEL USING REFERENCE CLASS-A
• THE CLASS-B SURFACE ARE CREATED BY THE EXTRACTION OF CLASS A SURFACE
• CLASS-C SURFACE CREARE BY THE BOUNDARY OF CLASS-A USING THE SWEEP COMMENT

METHODOLOGY

• IN THIS MODEL WE ARE CONSIDER THE FOLLOWING THINGS

1. TOOLING AXIS
2. DRAFT ANALYSIS
3. CLASS-A SURFACE
4. CLASS-B SURFACE
5. CLASS-C SURFACE
6. MAKING THE SOLID MODEL
