Photo Realistic Rendering

OBJECTIVE:
To model and render American chopper by using solidworks.

MODELLING:
chopper has the parts as follows
1.chassis
2.Engine
3.Front fork
4.Pedal
5.Chain
6.Oil tank
7.Gas tank
8.Transmission belt
9.front fender
10.Rear fender
11.Front wheel
12.Rear wheel
13.Kick stand
All the parts are designed separately and nally assembled together to get the nal American chopper.

Week1:
PARTS:1.Transmisson belt 2.kick stand 3.front fender
Command’s used:

Lines and circles
Extrude
revolve
Dome
Fillet

Week2:
PARTS:4.Oil tank 5.Chain 6.Pedal
Command’s used:

2d sketch
Sweep
Revolve
splines
Trim
Extrude cut

Week3:
PARTS:7.Front wheel
Command’s used:
2d sketch
Sweep
Revolve cut
Circular pattern
combine
Extrude cut
Revolve

Week4:
PARTS:8.Rear wheel 9.Front fork

Command’s used:
3d sketch
Sweep
Revolve
Mirror pattern
Dome
Projected curve
combine

Week5:
PARTS: 10.Chassis 11.engine
Command’s used:

Sweep
Revolve
Extrude
Dome
Projected curve
Split
Mirror

Week6:
PARTS: 12.Gas tank
Command’s used:
Surface loft
urface Sweep
Boundary surface
Revolve*Extrude

ASSEMBLY OF AMERICAN CHOPPER:
To make the assembly of American chopper we have to use some of the mates. They are following below
concentric mate
Parallel mate
Angle mate
Distance mate
Advance mate
PHOTOVIEW360 RENDERING
