Structural Engineering in High-Rise Buildings: Design Principles and Innovations

Over the years, there has been a significant increase in the number of high-rise buildings worldwide. This growth can be attributed to the continuous desire of humans to evolve, innovate, and develop without adverse consequences. High-rise building designs have seen advancements in various aspects, such as enhancing accessibility and strengthening foundations.

In addition to the latest structural innovations in high-rise buildings, there have been notable innovations in damping systems, construction techniques, elevator systems, and sustainability. While it may not be feasible, there is speculation about the world's first levitating building in the distant future— a remarkable achievement that sounds like something straight out of a sci-fi film.

This blog will explore the latest innovation in high-rise buildings, delving into the details to comprehensively understand these transformative developments.

History of High-Rise Buildings

The advent of the technological revolution in the United States between 1880 and 1890 marked a significant turning point in architecture and civil engineering. This period witnessed a surge in creativity and innovation, leading to the construction of skyscrapers that surpassed anything built before. Several essential inventions and advancements played a pivotal role in enabling architects to design and construct taller structures with enhanced flexibility and safety measures.

• One crucial development during this time was the introduction of Bessemer steel. This type of steel, shaped into I-sections through new rolling mills, offered durability and superior strength compared to the cast iron used in previous constructions.
• Another significant breakthrough was the invention of the sprinkler head. With the patenting of this innovative device, buildings were no longer limited to a strict height restriction of 23 metres.
• Additionally, patenting alternating current (AC) electricity profoundly impacted high-rise building design. The availability of AC electricity enabled the adoption of electrically powered elevators, making it feasible to transport occupants vertically to heights of ten stories or more.
• The combined impact of these technological advancements led to a burst of creativity and innovation in architectural design and civil engineering. Skyscrapers began to emerge as symbols of progress and modernity, transforming city skylines and forever changing the possibilities in building construction.

It is truly remarkable to consider how these innovations of the late 19th century laid the foundation for the remarkable high-rise buildings we see today. As technology advances, we can only imagine the exciting high-rise buildings' evolution and innovation in the future.

Top 5 Groundbreaking Innovations and Trends in High-Rise Building Designs

We are about to uncover five remarkable innovations that have revolutionised the realm of high-rise building construction:

• KONE UltraRope

One groundbreaking innovation transforming high-rise building construction is the introduction of KONE UltraRope. This cutting-edge carbon-fibre hoisting technology has revolutionised elevator systems, offering unprecedented benefits in both distance and efficiency.

At the core of KONE UltraRope is a lightweight carbon fibre core with an epoxy-based high-friction coating. This ingenious composition effectively doubles the distance an elevator can travel within a single shaft, reaching an impressive 1 kilometre. By significantly reducing the weight of the ropes, it profoundly impacts elevator-moving masses.

Traditionally, the weight of the ropes, compensating ropes, hoisting ropes, elevator car, counterweight, and passenger load limit elevator travel height. Typically, elevators are restricted to a single-shaft height of around 500 metres due to the practical constraints imposed by the thickness and mass of steel ropes. However, with the implementation of UltraRope, high-rise buildings can now accommodate elevators that can travel up to 1,000 metres without transferring lobbies.

• RASTER Façade Precast Concrete System

A remarkable innovation in high-rise building construction is the implementation of the Raster Façade. This load-bearing precast concrete frame offers numerous advantages over traditional construction methods. This innovative system enables the removal of interior columns in tall buildings, creating vast floor-to-ceiling glass surfaces made possible by triple-glazing, complemented by external retractable protective louvres. By maximising transparency, the Raster Façade generates a visually stunning aesthetic while optimising the usable floor area compared to alternative systems.

The precast façade design achieves an ideal ratio of sixty percent glazed to forty percent closed surfaces, resulting in improved insulation values. This composition enhances energy efficiency by reducing heat transfer through the façade. In addition, the Raster Façade system allows for integrating heating and cooling systems into suspended ceiling panels, a more efficient approach compared to conventional floor-mounted installations.

Another significant advantage of the Raster Façade lies in the inherent fireproof properties of precast concrete. The system ensures enhanced safety and simplifies construction processes by eliminating the need for additional fire protection measures, such as fireproof claddings or coatings. This innovative approach highlights the potential of load-bearing precast concrete as a compelling alternative to traditional glass curtain wall systems in high-rise building construction.

• MEGA TRUSS Seismic Isolation Structure

The design of a multipurpose high-rise building presented the unique challenge of accommodating two distinct requirements within a single structure. To address this, designers employed an integrated structural solution capable of safely transferring forces and seamlessly transitioning between different functions. The innovative approach achieved a harmonious coexistence of a concert hall and modern offices, each with specific demands and constraints.

The concert hall component of the building was constructed using reinforced concrete walls, forming a rigid frame that provides optimal acoustic performance and sound isolation. This design choice ensures an immersive musical experience for audiences while maintaining the necessary structural integrity.

Situated above the concert hall, the office spaces called for maximum flexibility, which led to the preference for column-free areas. An intermediate seismic isolation system, the Mega Truss, was strategically incorporated to achieve this. This system comprises mega columns, a belt truss, diagonals, lead rubber bearings, and oil dampers, effectively enabling the coexistence of these contrasting requirements within the same building.

Implementing this innovative structural system has significantly pushed the boundaries of high-rise construction, particularly in seismically active areas. The Mega Truss deserves recognition for its ability to transfer forces and integrate base isolation into remote systems, allowing for the realisation of isolated, tall buildings.

• BSB Prefabricated Construction Process

The BSB (Broad Sustainable Building) has garnered significant attention in the construction industry for its groundbreaking approach to building construction. The Broad Group achieved an extraordinary feat by developing and erecting T30, a thirty-storey building in Changsha, China, in an astonishing fifteen days, using only pre-assembled components.

The BSB construction process revolves around a factory-fabricated steel structure system. High-strength bolts and flanges are employed during on-site installation to secure the construction members, ensuring stability and structural integrity. The process also incorporates installable and integrated floor slabs, wallboards, and other prefabricated materials.

This innovative construction method offers a multitude of advantages for buildings:

• First and foremost, it provides exceptional seismic resistance, with the ability to withstand a magnitude-9 earthquake.
• In addition to its seismic resistance, BSB construction exhibits unparalleled energy efficiency. These structures boast five times the energy efficiency of conventionally constructed buildings, resulting in reduced energy consumption and environmental impact.
• An additional benefit of the BSB construction process is its remarkable waste reduction. BSB has generated less than one percent of the waste produced by traditional site-built construction methods by utilizing pre-assembled components and minimizing on-site construction activities.

• ROCKER Façade Support System

Within the architectural marvel of the Poly Corporation Headquarters lies an exceptional design component tailored specifically for high-rise buildings: The Rocker. This pioneering Rocker Façade serves a dual purpose by supporting expansive cable-net glass walls while actively mitigating the immediate effects of severe earthquakes and winds. In addition, it enables the suspension of an awe-inspiring, lantern-like museum structure within the atrium of an 80-storey office building.

Thorough structural analysis has revealed that a conventional two-way cable net cannot reasonably accommodate the support system required for a towering, twenty-two-story glass atrium wall. Instead, this challenge is overcome by breaking down the colossal enclosure, measuring sixty-five meters in width and ninety meters in height, into smaller segments. Introducing a cable-stayed system becomes pivotal, utilizing two large-diameter parallel bridge cables anchored to the eight-story museum structure, thus providing the necessary structural stability.

The significance of this innovative solution extends beyond the Poly Corporation Headquarters. It can be adapted to address unique circumstances encountered in other tall buildings, particularly those where construction workers must be liberated from direct involvement in the crosswise systems of the structures. Ensuring the safety of construction workers remains paramount, and incorporating such innovations reflects a steadfast commitment to their well-being.

Conclusion

With rapid technological advancements, the construction industry will continue to witness remarkable innovations in high-rise building construction. Staying informed, adapting quickly, and acquiring relevant skills through specialised courses are essential steps for aspiring civil engineers and professionals to embrace these changes and make the most of the opportunities they present.

One effective way to equip oneself with the necessary skills and knowledge is to enrol in a comprehensive high-rise building design and analysis course, such as the one offered by Skill-Lync. These courses provide a robust learning platform that covers all aspects of high-rise building design and analysis, enabling you to gain in-depth expertise and stay at the forefront of the industry.
