Week 3-Meshing of Hood Challenge

Hey Guys,

For this week's challenge,

Follow the below-mentioned quality criteria, mesh the component given below and assign thickness:

Target Element Length = 5 Units

S.N	Quality Criteria	Value
1	Aspect Ratio	5
2	Skewness	45
3	Warping	15
4	Taper	0.5
5	Min. Length	2 Units
6	Max. Length	8 Units
7	Min angle Quad	45
8	Max angle Quad	135
9	Min angle Tria	20
10	Max angle Tria	120
10	Tria %	10

(Note: Attach the hypermesh model files (.hm) with the challenge)

You will have to submit a detailed report describing whatever you have performed in the challenge. You will be graded for the report as well

 You can you any of the files provided (igs, hm or stp files) for this challenge. All are same cad model but of different format.
