Transient Structural Analysis on a Worm Gear Assembly using Ansys
Objective - To perform a transient structural analysis on a worm gear assembly and determine the Total Deformation, Equivalent Stress and Equivalent Elastic Strain developed in the model.
Procedure -
Create Transient structural analysis and in engineering data select the material structural steel.
Structural Steel.
Import the geometry and check in SpaceClaim for any irregularities.
Then open Ansys mechanical and rename the component as Worm and Gear then assign the structural steel material to all components.
Contact - one contact created as frictionless contact.
Frictionless - Worm To Gear
Joints
Revolute - Ground To Gear
Revolute - Ground To Worm
Mesh - Mesh the whole geometry with 2.5mm element size.
Analysis Settings - The simulation runs for 30 steps. So, the number of steps is set as 30.
Large deflection set to on, weak springs set to program controlled, auto time stepping to on, defined by time. Initial time step set to 0.2s, Minimum time step set to 0.2s and Maximum time step set to 0.5s. For second to thirty step set carry over time step to on. In Output control set all output to yes.
Joint - Rotation - the revolute joint on the worm is provided a rotation of 1500 degrees.
Run the simulation and results obtained.
Result - The analysis runs successfully and results obtained.
Total Deformation Max - 14.395 mm
Equivalent Stress Max - 1619.8 Mpa
Equivalent Strain Max - 0.008242 mm/mm
Animation Total Deformation
Conclusion -
- The maximum stress occurs at point of contact.
- The maximum deformations are basically measurements of displacement of a worm gear assembly with respect to its initial position.
- The maximum stress and strain is observed at the teeth root of gear .
