Multivariate Newton-Raphson method

The purpose of this assignment is to create a Python program including a Multivariate Newton Rhapson Solver, to solve a non-linear coupled differential system. This method is really useful for stiff systems, where the explicit solver are unstable.

The system of equations is:

`dy_1/dt = -0.04*y_1 + 10^4*y_2*y_3`

`dy_2/dt = 0.04*y_1 - 10^4*y_2*y_3 - 3*10^7 *y_2^2`

`dy_3/dt = 3*10^7 *y_2^2`

This multivariate method is based on the original Newton Rhapson solver. In each time step, the iteration process for the multivariate Newton Rhapson method takes place. For that, the following equation is used iteratively, starting by guessing a value for Xold.

`X^(n+1) = X^n - alpha*J^-1F`

In here, J is the Jacobian matrix, and X and F are column vectors of the dimension of the system; and alpha is the relaxation factor. For this program, the Jacobian has been computed numerically, as not always the analytical derivatives are available. As an example, we leave here how to compute a Jacobian component numerically.

`(df_i)/(dx_j) = (f_i(x_j + epsilon) - f_i(x_j))/epsilon`

The solution for the previous system is represented in the following image.

"""
Program to solve a system of differential
non-linear coupled equations

	dy1/dt = -0.04*y1 + 10^4*y2*y3
	dy2/dt = 0.04*y1 - 10^4*y2*y3 -3*10^7*y2^2
	dy3/dt = 3*10^7*y2^2

# We will use a BDF using Multivariate Newton Raphson Method

	f1 = y1(n-1) + dt*(-0.04*y1(n) + 10^4*y2(n)*y3(n)) - y1(n) = 0
	f2 = y2(n-1) + dt*(0.04*y1(n)-10^4*y2(n)*y3(n)-3*10^7*y2(n)^2) - y2(n) = 0
	f3 = y3(n-1) + dt*(3*10^7*y2(n)^2) - y3(n) = 0

"""
import math
import numpy as np
from numpy.linalg import inv
import matplotlib.pyplot as plt

#Problem Parameters
a1 = -0.04
a2 = 1e4
a3 = 3e7

#Variables for the time loop
dt=0.05
t_final = 10*60
t_initial = 0


def f1(y1_old,y1,y2,y3,dt):
	return y1_old + dt*(a1*y1 + a2*y2*y3) - y1

def f2(y2_old,y1,y2,y3,dt):
	return y2_old + dt*(-a1*y1-a2*y2*y3-a3*y2**2) - y2

def f3(y3_old,y1,y2,y3,dt):
	return y3_old + dt*(a3*y2**2) - y3

def jacobian(y1,y2,y3,dt):
	J = np.ones((3,3))

	#Row 1
	J[0,0] = -0.04*dt - 1
	J[0,1] = 10**4*y3
	J[0,2] = 10**4*y2

	#Row 2
	J[1,0] = 0.04*dt
	J[1,1] = dt*(-10**4*y3 - 6*10**7*y2) - 1
	J[1,2] = dt*(-10**4*y2)

	#Row 3
	J[2,0] = 0
	J[2,1] = dt*(6*10**7*y2)
	J[2,2] = -1

	return J

#Defining the initial and guess values
y1 = 1
y2 = 0
y3 = 0
#numpy column vector
Y_old = np.ones((3,1))
#numpy column vector
Y_guess = np.ones((3,1))

#numpy time vector
t = np.arange(t_initial,t_final,dt)
total_iter = len(t)

#numpy solution matrix
Y = np.ones((3,total_iter))

#numpy column vecotr for F
F = np.copy(Y_guess)

#Starting the Time integration Loop
time_iter = 0

for i in range(1,total_iter+1):

	Y_old[0] = y1
	Y_old[1] = y2
	Y_old[2] = y3

	Y_guess[0] = y1
	Y_guess[1] = y2
	Y_guess[2] = y3

	#Parameters for Newton Raphson solver
	error = 9e9  #Initializing error
	alpha = 1
	tol = 1e-8

	#Starting the Newton Raphson loop
	iter = 1

	while error > tol:

		#Computing the F vector - old values are used
		F[0] = f1(Y_old[0], Y_guess [0], Y_guess[1], Y_guess[2], dt)
		F[1] = f2(Y_old[1], Y_guess [0], Y_guess[1], Y_guess[2], dt)
		F[2] = f3(Y_old[2], Y_guess [0], Y_guess[1], Y_guess[2], dt)

		#Computed the Analytical Jacobian  - old values are used
		J = jacobian(Y_guess[0], Y_guess[1], Y_guess[2], dt)
		#print(J)

		# Computing the Numerical Jacobian
		n=len(Y_guess)
		eps = 1e-8
		Y_perturb = np.copy(Y_guess)
		F_perturb = np.zeros((3,1))
		Jac = np.zeros((3,3))
		k=0
		for i in range(n):

			Y_perturb[i] = Y_guess[i] + eps
			F_perturb[0] = f1(Y_old[0], Y_perturb[0], Y_perturb[1], Y_perturb[2], dt)
			F_perturb[1] = f2(Y_old[1], Y_perturb[0], Y_perturb[1], Y_perturb[2], dt)
			F_perturb[2] = f3(Y_old[2], Y_perturb[0], Y_perturb[1], Y_perturb[2], dt)
			Jac[0,i] = (F_perturb[0] - F[0])/eps
			Jac[1,i] = (F_perturb[1] - F[1])/eps
			Jac[2,i] = (F_perturb[2] - F[2])/eps
			#print(X_perturb)
			Y_perturb[i] = Y_guess [i]
		#print(Jac)

		#Computing the new values
		Y_new = Y_guess - alpha*np.matmul(inv(Jac),F)

		#Computing max abs error
		error = np.max(np.abs(Y_new-Y_guess))

		#Updating old values
		Y_guess = Y_new

		#log message
		log_message = 'iteration # = {0} y1={1} y2={2} y3={3}' .format(iter,Y_new[0],Y_new[1],Y_new[2])
		print(log_message)
		iter = iter + 1

	#Final results
	y1 = Y_new[0]
	y2 = Y_new[1]
	y3 = Y_new[2]

	Y[0,time_iter]= Y_new[0]
	Y[1,time_iter]= Y_new[1]
	Y[2,time_iter]= Y_new[2]

	time_iter = time_iter + 1

#Make sure the size of the matrix and time vector corresponds
size = np.shape(Y)
print(size)
print(total_iter)

plt.plot(t,Y[0,:],color='black')
plt.plot(t,Y[1,:],color='orange')
plt.plot(t,Y[2,:],color='blue')
plt.legend(['Y1','Y2','Y3'])
plt.show()
