Analysis of a Low Voltage control panel using ANSYS Icepak

A comprehensive course on Low Voltage Control Panel Analysis using ANSYS ICEPAK. This course is highly suited for beginners

  • Duration : 1 Month
  • Domain : MECHANICAL ENGINEERING, ELECTRICAL AND ELECTRONICS ENGINEERING, THERMAL ENGINEERING
  • Benefits : A comprehensive course on Low Voltage Control Panel Analysis using ANSYS ICEPAK. This course is highly suited for beginners
  • Price : 30000
Start project View demo
About Demo Leaderboard

What will you do in this project?

In this project, you will do the following in this project,

  • Model the low voltage control panel components asper the dimensions provided.
  • Setup the Joule's heating power for busbars and cables as per the configurations provided.
  • Run the simulation in parallel with settings and parameters related to Natural convection analysis.
  • Visualize the results and Verify the temperature rise in the panel.

  • Modelling the Low voltage control panel using ANSYS Icepak
  • Setting up the Constant and Joule's heating power for Circuit breakers, busbars and cables asper the configuration
  • Run the simulation with the settings and parameters required for a Natural convection analysis.
  • Post-process the results and Verify the temperature rise in the system.

Related Projects

See all
Analysis of a 3D Fan using MRF approach in ANSYS Icepak

A comprehensive course on 3D Fan using MRF Approach using ANSYS ICEPAK. This course is highly suited for beginners
Thermodynamic analysis of a commercial application tractor engine

In this project you will be using the GT-Power tool to apply the CI engine calibration methodologies to help aid the cause by targetting crucial diesel engine parameters like BSFC, Equivalence ratio,Injection pressures, and Combustion model parameters for a turbocharged system with and without a EGR assembly
Flow over the FSAE racing car

In this project, you will be setting up the cases for the FSAE racing car in Converge CFD software and then simulating them to analyse the drag force and the down force experienced by each component of the FSAE car.

Project Highlights

The project is an advanced level project
  • This project is great for undergraduate students (3rd & 4th year), M.Tech or MS students
  • If you are a working professional, this project will be helpful to learn Thermal management in Electronic systems
Pre-requisites
  • Must be comfortable with ANSYS Icepak
  • Need basic background in CFD
Work with Multiple Tools
  • You will learn ANSYS Icepak
  • You will learn how to setup a thermal analysis on electrical systems accounting power losses in transmission
  • You will learn how to post process the results and analyse the hot zones for improving performance

Analysis of a Low voltage control panel

In this project, We will be modelling a Low voltage control panel with circuit breakers, busbars, power cables, etc in ANSYS Icepak and will be analysing the flow pattern in the cabinet and temperature rise in the system by accounting the power loss in the transmission by incorporating Joule's heating effect on the conducting components. Also you will be understanding the some of the important design considerations to be made for a natural convection analysis.

  • You will learn how to model a Low voltage control panel using ANSYS Icepak
  • You will learn the important design considerations and setup configurations to be made for a Natural convection analysis
  • You will learn to analyse the hot zones in the system for improving the performance of the system

FAQ

Frequently Asked Questions

1How is this project going to help me?

SKILL-LYNC projects are mapped closely with what industry expects. When you work on a SKILL-LYNC project and publish it in your profile, recruiters are automatically notified about your profile.  Your project submissions are graded so that students can get critical feedback on your work

2Can I add this project in my resume?

You bet!

3What are the pre-requisites for this project?

  • A few premium projects might require a prior understanding of fundamental concepts
  • In such a case, you will be given access to appropriate learning materials to first learn those concepts before jumping to the project
